Specifications

•
• Setting: 1-3 pulse settings
• Oxygen Concentration: 90% oxygen +5.5/-3%
•
• Dimensions: 8.6 in. high x 6.1 in. wide x 3.6 in. deep (21.8 cm high x 15.5 cm wide x 9.1 cm deep)
•
• Weight: 4.4 lb (2 kg); 1.8 lb (0.8 kg) - optional AirBelt
• Power: Universal Power Supply; AC Power: 100–240 VAC, 50/60 Hz (1.0 amp at 120 VAC) DC Power: 11–16 VDC (6.0 amps at 12 VDC) FreeStyle Unit: 28 W at the 3 setting
•
• Battery Duration: 3 setting - 2 hours; 2 setting - 2.5 hours; 1 setting - 3.5 hours
• Recharge Time: 3.5 hours
• AirBelt Duration: 3 setting - An additional 3 hours; 5 hours total with AirBelt 2 setting - An additional 3.5 hours; 6 hours total with AirBelt 1 setting - An additional 6.5 hours ;10 hours total with AirBelt
• Battery Cycle Life: Approximately 300 cycles, then 80% capacity or below
• Warm Up Time: 2 minutes
• Alarms Indicators: Start-up, Pulse flow, Battery condition/level, Cannula disconnect, System overdraw, General malfunction
• Temperature Range: Operational temperature: 41ºF to 104ºF (5ºC to 40ºC.) (Operating unit outside of this range can affect performance.) Storage temperature: -2ºF to 140ºF (-20ºC to 60ºC)
• Altitude: Up to 12,000 ft (3,657.6 m.) (Higher altitudes may affect performance.)
• Sound Level: 38 dBA at 1 setting; 41 dBA at 2 setting; 44 dBA at 3 setting
•
•

*Specifications subject to change without notice.
